Size Code
400 x 400 mm, 16 x 16” 8-400027-4
400 x 460 mm, 16 x 18” 8-400027-7
460 x 400 mm, 18 x 16” 8-400027-2
460 x 460 mm, 18 x 18” 8-400027-5
510 x 400 mm, 20 x 16” 8-400027-3
510 x 460 mm, 20 x 18” 8-400027-1
560 x 400 mm, 22 x 16” 8-400027-13
560 x 460 mm, 22 x 18” 8-400027-10
Includes two pelvic gel inserts to increase therapeutic support under pelvis
– Thick or thin inserts for customisable cushioning needs
– Fluid resistant, flame retardant, vapour permeable cover
– Hook and loop sections on base of cushion for attaching to a wheelchair
– 63.5mm high (without inserts) with 44.5mm of buckling gel under
pressure points
Dual layer design:
– The top layer consists of a thinner wall gel and tight grid for superior
immersion and comfort
– The base layer consists of a thicker wall gel and wider grid which
provides deep postural support
– 2-year warranty on insert
– 1 year warranty on cover
– Safe working load (SWL) 250kg
